LED wall light “DURAN”

LED wall light “DURAN”

LED wall light “DURAN”

Description

The DURAN are applique based on LED technology with contemporary design, refined elegance, a charm.

Optics wall washer sends the indirect light that enhances the volume of the room, leaning lightly on the wall and ensuring a strong presence but discreet.

Specifications

Technical specifications

Body: Die-cast aluminum structure with low copper content;

Power: 12-24 VDC -240 VAC, Class I and II, IP54;

Color Temperature: Warm White 3000°K, Neutral White 4000°K, Cold White (5000° or 6000° K), Red, Blu, Green, RGB;

Dimmering: Upon request predisposition for dimming analog / digital;

LED efficiency: 166 lm/watt;

Reference standards

[symbols ids=”2011/65/CE, 2006/95/CE, 2004/108/CE”]
Conforms to the group of risk-free RG=0; IEC 62471;
  • EN 60598-1
  • EN 62471
  • EN 55015
  • EN 61547
  • EN 61000-3-2
  • EN 61000-3-3
  • UNI EN 12464-1

Models

DURAN12

Photometric Dimensions

12 Watt, 4 LED, 1992 Lm (eq. Halogen 100 Watt), Beam angle 120°

DURAN35

Photometric Dimensions

35 Watt, 12 LED, 5810 Lm (eq. Halogen 300 Watt), Beam Angle 120°

DURAN60

Photometric Dimensions

60 Watt, 24 LED, 9960Lm (eq. Halogen 500 Watt), Beam Angle 120°

Options

Opzioni:

OpLUCO: Sistema elettronico di controllo per autoregolazione dell’illuminazione a LED;

OpCE1: Kit d’emergenza per lampade a LED;

OpDALI: sistema elettronico di controllo dell’illuminazione a LEd con protocollo standard DALI;

OpINLUX: Predisposizione per regolatore di flusso e/o telecontrollo PITECO;
