LED Street Lights “TRIANON”

LED Street Lights “TRIANON”

The street lighting TRIANON series are the newest solution for street lighting.

The TRIANON, with an efficiency of 185lm/watt, are among the most performing on the market. With a modern and refined design they are suitable for use in urban lighting and LED street lighting.

The TRIANON have been designed to obtain maximum energy and economic savings. Available in 7 basic powers can be customized on request of the customer. With more than 20 optics available they allow a wide choice and adaptability of lighting.

– Upon request the reinforcement can be made suitable for series plants.
Open with a simple click.

Technical specifications

Structure Die-cast aluminum structure with low copper content
Power 110-270 Vac, efficiency 94%, PFC>0,95, IP66 (also with voltage 12-24Vdc nad installation in series)
Color temp. 5000°K (choice of:  3000°, 4000°K)
Class II + T or class I
Painting Epoxy poweder finish resistant to UV rays et atmospheric agents.
Assembly Side and top pole mounting with adjustable tilt of + /- 15°, + /- 10° and  + /- 5°. For poles of max. 62 mm diameter.
Optical Group Wide choice. Complies with all laws and regulations existing in the field of light pollution.
Efficiency LEDs 185lm/watt
Reference standards EN 60598-1, EN 62471, EN 55015, EN 61547, EN 61000-3-2, EN 6100-3-3, UNI EN 10819, UNI11248, EN13201
Directives 2011/65/CE, 2006/95/CE, 204/108/CE

Dimensions

Photometric now available

TRIANON 20

Power consumption 20 Watt
Replaces MBF80
Luminous flux on the LED 3700 lm
Number of LED* 12
Weight** 7,4 Kg

TRIANON 30

Power consumption 30 Watt
Replaces SAP70 and MBF125
Luminous flux on the LED 5550 lm
Number of LED* 12
Weight** 7,50 kg

TRIANON 40

Power consumption 40 Watt
Replaces SAP100 and JM150
Luminous flux on the LED 7400 lm
Number of LED* 12
Weight** 7,50 Kg

TRIANON 60

Power consumption 60 Watt
Replaces SAP150 and BMF250
Luminous flux on the LED 11100 lm
Number of LED* 24
Weight** 7,60 Kg

TRIANON 90

Power consumption 90 Watt
Replaces SAP250
Luminous flux on the LED 16650 lm
Number of LED* 36
Weight** 7,60 Kg

TRIANON 120

Power consumption 120 Watt
Replaces SAP400
Luminous flux on the LED 22200 lm
Number of LED* 36
Weight** 8 Kg

TRIANON 150

Power consumption 150 Watt
Replaces JM600
Luminous flux on the LED 27750 lm
Number of LED* 36
Weight** 8 Kg

* This value may be subject to change without notice, so please ask for confirmation when ordering.

** +/- 5%.

Opzioni

OpDARF1: Dimmering autonomo senza possibilità di settaggio;

OpDAR2: Dimmering autonomo con impostazione dell’ora di attivazione;

OpINLUX: Predisposizione per regolatore di flusso e/o telecontrollo PITECO;

OpRAYBOX: Scaricatore di sovratensione 20KA montato nell’armatura;
