LED CEILING “PLEDOUT”

LED CEILING “PLEDOUT”

With PLEDOUT will open the way to the third generation of this family of ceiling suspension with the use of LED sources.
A mechanical structure with the possibility of dry surface-mounted, suspended or wall in single or multiple configurations.
LED technology allows you to extract that contains high luminous flux with high efficiencies (with a PLEDOUT045 from 40watt can replace a 2×58 in neon).

Customers tend to use LED tubes and insert them in neon ceiling lights, replacing the classic neon, with adaptation cabling. As you can read from the PDF and from the following link, this technique causes  to be lost the CE certification into the ceiling light:

Lampade a LED con attacco G5 e G13: rischi e responsabilità (ASSIL – TECHNICAL STATEMENT)

http://www.luxemozione.com/2013/01/tubi-led-vs-fluorescenti-vera-convenienza.html

Technical specifications

Body: Realized in aluminum with low copper content;

Power: 110-270Vac, efficiency 94%, PFC>0,95, IP65 CLASS I and II+T;

Color Temperature: 5000°K (choice of 3000°, 4000° K);

Mounting: mounted suspended or on the wall;

Photobiological safety: Conforms to the group of risk-free RG0, IEC 62471;

LED efficiency: 166 lm/watt;

Reference standards

  • 2011/65/CE
  • 2006/95/CE
  • 2004/108/CE

Conforms to the group of risk-free RG=0; IEC 62471;

  • EN 60598-1
  • EN 62471
  • EN 55015
  • EN 61547
  • EN 61000-3-2
  • EN 61000-3-3
  • UNI EN 12464-1

Dimensions

Type of attacks

Body colours available

Photometrics now available

PLEDOUT14

Power consumption 12 Watt
Number of LED* 4
Luminous intensity on the LED 1992 lm
Replace 2×18 or 1×36 to neon
Dimensions 300x100x64 mm
Weight** 0,8 Kg

PLEDOUT28

Power consumption 25 Watt
Number of LED* 8
Luminous intensity on the LED 4150 lm
Replace 2×36 to neon
Dimensions 600x100x64 mm
Weight** 1,9 Kg

PLEDOUT45

Power consumption 40 Watt
Number of LED* 12
Luminous intensity on the LED 6640 lm
Replace 2×58 to neon
Dimensions 1200x100x64 mm
Weight** 3,0 Kg

PLEDOUT56

Power consumption 50 Watt
Number of LED* 16
Luminous intensity on the LED 8300 lm
Replace 2×58 to neon
Dimensions 1500x100x64 mm
Weight** 3,5 Kg

* This value may be subject to change without notice, so please ask for confirmation when ordering.

** +/- 5%.

OpLUCO: Sistema elettronico di controllo per autoregolazione dell’illuminazione a LED;

OpCE1: Kit d’emergenza per lampade a LED;

OpDALI: sistema elettronico di controllo dell’illuminazione a LEd con protocollo standard DALI;

OpINLUX: Predisposizione per regolatore di flusso e/o telecontrollo PITECO;
